Extend an Ultra-HD 4Kx2K 30Hz DisplayPort monitor, audio, USB keyboard, USB mouse, and RS232 up to 328 feet (100 m) via CATx or 6.21 miles (10 km) via fiber.
XTENDEX® ST-C6FOUSBDP4K-LC
XTENDEX® ST-C6FOUSBDP4K-LC

4K 10.2Gbps DisplayPort USB KVM Extender via One CAT6/7 Cable or LC Singlemode/Multimode Fiber Optic Cable

NTI Part #: ST-C6FOUSBDP4K-LC-Group
The XTENDEX® 4K 10.2Gbps DisplayPort USB KVM Extender via CAT6/7 or Fiber provides remote KVM (USB keyboard, USB mouse and 4Kx2K 30Hz UHD DP monitor) access to a USB computer up to 328 feet (100 m) away via CAT6/6a/7 cable, 6.21 miles (10 km) via simplex LC singlemode fiber optic cable, or 1,640 feet (500 m) via simplex LC multimode fiber optic cable.

Each KVM extender consists of a local unit that connects to a computer, and a remote unit that connects to a DisplayPort monitor, bi-directional 3.5mm stereo audio speakers and microphone, RS232, and up to four USB devices (keyboard, mouse, flash drive, HDD, touchscreen display, etc).
  • Extend 4Kx2K @30Hz up to 328 feet via CATx or 6.21 miles via fiber.
  • 4 transparent USB connectors for keyboard, mouse, flash drive, HDD, touchscreen display, etc.
  • ROHS Compliant 4K 10.2Gbps DisplayPort USB KVM Extender via One CAT6/7 Cable or LC Singlemode/Multimode Fiber Optic Cable
  • CE Compliant 4K 10.2Gbps DisplayPort USB KVM Extender via One CAT6/7 Cable or LC Singlemode/Multimode Fiber Optic Cable
  • FCC Compliant 4K 10.2Gbps DisplayPort USB KVM Extender via One CAT6/7 Cable or LC Singlemode/Multimode Fiber Optic Cable
Scroll Down to Get Quote

Overview

The XTENDEX® 4K 10.2Gbps DisplayPort USB KVM Extender via CAT6/7 or Fiber provides remote KVM (USB keyboard, USB mouse and 4Kx2K 30Hz UHD DP monitor) access to a USB computer up to 328 feet (100 m) away via CAT6/6a/7 cable, 6.21 miles (10 km) via simplex LC singlemode fiber optic cable, or 1,640 feet (500 m) via simplex LC multimode fiber optic cable.


Each KVM extender consists of a local unit that connects to a computer, and a remote unit that connects to a DisplayPort monitor, bi-directional 3.5mm stereo audio speakers and microphone, RS232, and up to four USB devices (keyboard, mouse, flash drive, HDD, touchscreen display, etc).

  • Supports Ultra-HD 4Kx2K resolutions to 3840x2160 @30Hz YUV 4:4:4, HDTV resolutions to 1080p @60Hz, and up to 1920x1200 (WUXGA).
  • Signal transmission via one CAT6/6a/7 cable or one single-strand singlemode/multimode LC fiber optic cable.
    • Using CAT6/6a/7 cable:
      • Extend a 4Kx2K signal up to 328 feet (100 m).
      • Extend a 1080p or 1920x1200 signal up to 492 feet (150 m).
    • Using singlemode 9-micron cable, extend to 6.21 miles (10 km).
    • Using multimode 50-micron cable, extend to 1,640 feet (500 m).
  • DisplayPort features supported:
    • DisplayPort 1.2
    • 36-bit Color
    • RGB, YCbCr 4:4:4, TCbCr 4:2:2
    • Dolby, DTS, Stereo, and LPCM Audio
    • Bandwidth up to 340 MHz (10.2 Gbps)
  • HDCP compliant.
  • Four transparent USB ports for self-powered and/or bus-powered USB peripheral devices (security cameras, printers, scanners, touch screen monitors, game controllers, flash drives, keyboards, mice, etc.).
    • Keyboard and mouse are hot-pluggable.
  • Supports Plug-and-Play specification.
  • Using an unmanaged Gigabit network switch, extend up to 32 pairs in Point-to-Point connections.
    • Use the DIP switch on the transmitter and receiver to specify the ID for the unit.
      • Transmitter and receiver units with the same ID will connect to each other. (Only Point-to-Point connections are supported.)
  • Supports full-duplex RS232 up to 115200 baud.
  • EDID pass-through for the support of any DisplayPort monitor
  • Mounting brackets included for easy surface/wall mounting.

Specifications

Local Unit
  • Compatible with a USB computer with Ultra-HD DisplayPort output.
  • Multiplatform support: Windows 7/10/11, Linux, and MAC OS 10/11.
  • One female DisplayPort connector.
  • One female USB Type B connector.
  • Two female 3.5mm stereo jacks for audio out and mic in.
  • 3-pin screw terminal for RS232.
    • Support full-duplex RS232 up to 115200 baud.
  • One female RJ45 port for sending/receiving video, audio, USB, and RS232 signals.
  • One simplex female LC fiber optic port for sending video, audio, USB, and RS232 signals.
  • DIP switch for specifying unit ID.
  • HDCP compliant.
Remote Unit
  • One female DisplayPort connector.
  • Four transparent female USB 2.0 Type A connectors.
    • Supports high-speed (480 Mbps), full-speed (12 Mbps), or low-speed (1.5 Mbps) USB devices - keyboard, mouse, game controller, USB flash drive, touch screen monitor, whiteboard, etc.
  • Two female 3.5mm stereo jacks for audio out and mic in.
  • 3-pin screw terminal for RS232.
    • Support full-duplex RS232 up to 115200 baud.
  • One female RJ45 port for sending/receiving video, audio, USB, and RS232 signals.
  • One simplex female LC fiber optic port for sending/receiving video, audio, USB, and RS232 signals.
  • DIP switch for specifying unit ID.
  • Supported video resolutions:
    • Ultra-HD 4Kx2K resolutions to 3840x2160 @30Hz YUV 4:4:4
    • HDTV resolutions to 1080p @60Hz
    • Up to 1920x1200 (WUXGA)
  • Supports embedded digital audio through DisplayPort-compatible monitors or audio receivers.
  • HDCP compliant.
Power
  • Local unit:
    • Input: 100 to 240 VAC at 50 or 60 Hz via AC adapter (included).
    • Output: 12VDC, 2A
    • Power consumption: 3W
  • Remote unit:
    • Input: 100 to 240 VAC at 50 or 60 Hz via AC adapter (included).
    • Output: 12VDC, 2A
    • Power consumption: 15.6W
    • The current passing through each USB port cannot exceed 0.5A.
Dimensions
  • WxDxH (in): 6.3x4.29x1.12 (160x109x29 mm)
Environmental
  • Operating temperature: 32 to 131°F (0 to 55°C).
  • Storage temperature: -4 to 185°F (-20 to 85°C).
  • Operating relative humidity: 5 to 90% non-condensing RH.
Regulatory Approvals
  • CE, FCC, RoHS
  • TAA compliant
Warranty
  • Two years
Max Distance
  • Using CAT6/6a/7 cable:
    • Extend a 4Kx2K signal up to 328 feet (100 meters).
    • Extend a 1080p or 1920x1200 signal up to 492 feet (150 meters).
  • Using singlemode 9-micron cable, extend to 6.21 miles (10 km).
  • Using multimode 50-micron cable (OM2 and above), extend to 1,640 feet (500 meters).
Cables
  • Interface cables between the source/display and the transmitter/receiver are required for proper operation.
  • Use DP-xx-MM to connect a DisplayPort source or display up to 15 feet (not included).
  • Use DP8K-FO-xxM-MMLC or DP8K-FOCMP-xxM-MM active optical cable to connect a DisplayPort monitor up to 100 meters (not included).
  • One 6 ft (1.85 m) male USB Type A to male USB Type B interface cable included.
  • Use CAT6/6a/7 cable terminated with standard RJ45 connectors to extend the receiver from the transmitter (not included).
    • Extend a 4Kx2K signal up to 328 feet (100 meters).
    • Extend a 1080p or 1920x1200 signal up to 492 feet (150 meters).
  • Use a simplex singlemode LC 9-micron fiber optic cable to extend the receiver from the transmitter up to 6.21 miles (10 km). Not included.
  • Use a simplex multimode LC 50-micron (OM2 and above) fiber optic cable to extend the receiver from the transmitter up to 1,640 feet (500 m). Not included.
